Battery Cutoff Switch - SFCBS-275-201
Industry-Leading 4-Year Warranty!
Protect your RV by installing this SEAFLO Battery Master Switch. Rated at 275A continuous, 450A intermittent, 1250A cranking and 48V. Can be recessed or surface mounted.
Article number: | SFCBS-275-201 |
Availability: | In stock (105) |
The SEAFLO Battery Cut-Off Switch is crafted with durability and safety in mind. It is built to withstand the demands of marine and RV applications, offering reliable performance even in harsh environments. The robust construction ensures that the switch can handle high electrical currents while providing long-lasting durability.
This battery cut-off switch is specifically designed for 12V or 24V battery systems. It is suitable for a wide range of applications, including boats, RVs, and other vehicles where battery power management is crucial. The switch effectively cuts off the electrical connection between the battery and the load, preventing power drain and extending battery life when the vehicle or vessel is not in use.
The SFCBS-275-201 model features a compact and space-saving design, allowing for easy installation in tight spaces. Its streamlined profile ensures a neat and uncluttered appearance in your battery compartment or electrical panel.
Operating the SEAFLO Battery Cut-Off Switch is simple and user-friendly. With its easy-to-use knob or lever, you can easily toggle the switch between the "On" and "Off" positions. This provides convenient control over the power supply to your batteries, allowing you to conserve energy and prevent unwanted battery drain when the system is not in use.
Installing the SEAFLO Battery Cut-Off Switch is a straightforward process. With its universal design and clear instructions, you can easily connect the switch to your battery system, ensuring a secure and reliable electrical connection. The switch is typically installed between the positive terminal of the battery and the load, providing an efficient means to disconnect power when needed.
Upgrade your battery system with the SEAFLO Battery Cut-Off Switch, model SFCBS-275-201. With its durable construction, compact design, and user-friendly operation, this switch offers a reliable and convenient solution for managing your battery power. Ensure optimal battery performance and prolong their lifespan with this essential accessory.
Features & Benefits Removable side plates for access of up to 1/0 cables plus a rear cover insulating the rear terminals against any short circuits. ABS Anti-aging, Anti-ultraviolet. |
Typical Applications Marine RV & Campers Industrial |
Technical Date
Max.Volt (V) | 50 |
Amp Draw (A) | 275 |
Max Amp Draw (A) | 1250 |
Switch Position | 2 |
Packing Size | 78x78x80 mm |
N.W/GW | 0.20/0.30 kg |
